HISUN® delivers innovative solar energy solutions with a focus on reliability, sustainability, and cost savings. Our high-quality products ensure uninterrupted power and reduced dependence on the grid.
High-quality lithium iron phosphate battery cells, with better product performance and reliability.
Each battery module unit with an independent BMS system for scientific management of the cells.
Support multiple battery packs in parallel
-Support RS485/CAN communication, compatible with global mainstream inverters
Support mutiple install modes
-Life time reaches 6000 cycles
-Wider temperature range: -20°C-60°C
-Widely for home, stores and office use
| Specification | Model | HISUN-S100L |
|---|---|---|
| Electrical Specification | ||
| Rated battery voltage | 51.2V | |
| Rated power | 5.12kWh | |
| Nominal capacity | 100Ah | |
| Combination | 16S1P | |
| Cycle life | ≥6000cycles@80% DOD@25°C | |
| Monthly self-discharge | ≤3%/month | |
| Charge efficiency | ≥97% | |
| Discharging efficiency | ≥95% | |
| Recommended charging voltage | 57V | |
| Charging Standard | ||
| Maximum charging current | 20A | |
| Maximum charging voltage | 58.4V | |
| Recommended charging current | 10A | |
| Discharging Standard | ||
| Maximum discharge current | 100A | |
| Recommended discharge current | 50A | |
| Discharge cut-off voltage | 43.2V | |
| Physical | ||
| Dimensions (WDH)(mm) | 505480197mm | |
| Pack size (WDH)(mm) | 563558226mm | |
| Net weight(kg) | 47KG | |
| Gross weight(kg) | 51KG | |
| IP protection | IP65 | |
| Shell material | Metal | |
| Optional functions | FU… GUARD | |
| Environment | ||
| Charging temperature range | 0°C~45°C | |
| Operating temperature range | -20°C~60°C | |
| Storage temperature | -20°C~40°C | |
| Humidity | 10%~95% RH (No condensing) |
Wall-mounted lithium iron phosphate (LiFePO4) battery pack Features: High-quality lithium iron phosphate battery cells, with better product performance and reliability. Each battery module unit with an independent BMS system for scientific management of the cells. Support multiple battery packs in parallel -Support RS485/CAN communication, compatible with global mainstream inverters Support mutiple install modes Life time
+ Read More
Product introduction: HISUN-series is lithium iron phosphate battery pack(including BMS). It is composed of 16 strings of battery cells, all battery cells adopt intelligent sorting. Its voltage and current are accurate and reliable; Professional BMS board to protect the battery pack. It has high energy density, long life, safe and reliable, wide temperature range characteristics.
+ Read More
1.Rated Power : 15.36 KWH 2. support multiple battery pack in parallel. 3. widely use for home,stores and office. 4. net weight : 120 KGs.
Inquire Now
1.Rated Power : 5.12KWH 2. support multiple battery pack in parallel. 3. widely use for home,stores and office. 4. net weight 47 KGs.
